Name: Rock Drill T45 HD709 Striking Bar Shank Adapter
Brand: KSQ Technologies (Beijing) Co. Ltd
SKU: HD709
Price: 508.50 USD
Availability: InStock

Rumah Produk batu pengeboran alat

Rock Drill T45 HD709 Striking Bar Shank Adapter

Detail produk:

Tempat asal:	Cina
Nama merek:	MIROC
Sertifikasi:	ISO
Nomor model:	HD709

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1
Waktu pengiriman:	3 - 10 hari
Menyediakan kemampuan:	3000

Kontak

Detil Deskripsi produk

Kata Kunci:	Adaptor betis	Benang:	T38/T45
Proses Manufaktur:	Pengecoran	Perawatan Permukaan:	Karburasi Permukaan
Bahan:	Baja paduan

Shank adapters are used for transmitting power from the rock drill to the drill stems. Generally there are male threaded shank adapters and famal threaded shank adapters. Male shank adapters are more populaer than famale shank adapter. Male shank adapter are generally suited for drifting, tunneling and extension applications where high stresses are present. Females shankadapters are used when the drilling space is limited.

shank adapters ensure a quality drill string interface to the most exacting industry tolerances. Built to seamlessly interface with hydraulic and pneumatic drifters and top hammers, our shank adapters come in a full range of industry-standard thread configurations. Our precision grinding process ensures straightness, and our tools are fully carburized with an advanced heat treatment.

Different shank adapters are available, like Atlas Copco, Tamrock, Ingersoll Rand,etc. Also for the same drill machine, due to different applications, the shank adapters can be different length and different threads.

Atlas Copco (COP1238, COP1838, COP1032 and etc)

Furukawa (HD715, HD612, HD609, PD200 and etc)

Ingersoll-Rand (VL140, VL671, YH80A and etc)

Tamrock(HLX5, HL600, HL500, HL300, HL 700, HL850, HL1000, HL1500 and etc)

Product Name:	High Quality and china factory! shank adapter
Description:	High Quality and china factory! shank adapter drills Shank adaptor is used for transmitting power between drill machine and drill stems

MOQ:	1 Piece for testing and trial order
Thread:	R32,R38,T38,T45,T51
Length:	300mm-800mm
our shank adaptors are available for :	World top brand(COP1238,COP1838,COP1032 etc) Furukawa (HD715,HD612,HD609,PD200 etc) Ingersoll-Rand (VL140,VL671,YH80A etc) Tamrock(HLX5,HL600,HL500,HL300,HL700,HL850,HL1000,HL1500 etc)

Furukawa HD 709
Thread	Length (L) (mm)	Diameter (D) (mm)	Diameter at piston strike face (mm)	Spline type	Spline length (mm)	Spline diameter (mm)	Spline dimension (mm)	Special feature
T38	620	45	—	Straight	93	62.75	9.67	Standard
T45	620	45	—	Straight	93	62.75	9.67	Standard

Rock Drill T45 HD709 Striking Bar Shank Adapter 0

Rock Drill T45 HD709 Striking Bar Shank Adapter 1

Rock Drill T45 HD709 Striking Bar Shank Adapter 2

Rock Drill T45 HD709 Striking Bar Shank Adapter 3

Rock Drill T45 HD709 Striking Bar Shank Adapter 4
